Masonry Flashing for Exterior Openings

Words: Dan Kamys

By Joe Packhem

Moisture entering buildings has the potential to cause problems for the health and well being of the building inhabitants if the building envelope is not designed and constructed properly. Thus, the flashing of masonry for exterior openings is tremendously important to architects, engineers, and contractors.

Exterior doors and windows are gaps in the wall where the moisture drainage cavities are terminated. Water moves through exterior wall elements based on the porosity, a measurement of the small holes that allow air or liquid to pass through objects. When air enters the building, it is seen as leakage, and when moisture enters the building it is permeable. Parapets, openings, masonry units, and foundation bases could allow moisture to get inside the wall.

Constant moisture alone can be accommodated; however, trapped moisture has a chance to freeze and thaw on the inside of the wall, causing damage as well as efflorescence. Flashing of parapets and openings are the primary defenses of a wall system to channel the exit of the moisture.

Openings in the wall for windows and doors require structural designs to transmit the load to the edges of the opening with lintels or arches. The weight of the wall above the opening can be carried across the span by steel, concrete, or masonry. Different lintel materials and shapes affect the flashing for the moisture control of the opening. Lintels are designed based on many factors including the span, load, and whether arching action occurs in the masonry above the opening.

There are three different types of flashing that can be used to prevent moisture penetration: metal, composite, and plastic (elastomer). Designing flashing for the duration of the structure plays a key role in determining the type of flashing to use. Steel and copper are the metal alternatives, which provide the best durability/longevity in the wall. These also are the most expensive choices, but are great for buildings with more than a 100-year design life such as many publically funded projects. Note that copper flashing can stain the bricks over time as the metal oxidizes.

Because of this potential discoloration to the masonry exterior, composite materials have been created to laminate to the copper. The adhesive bond between the copper and plastic film may shrink or separate over time. Aluminum flashing with a laminate is workable, and can be cut with scissors. Plastic (elastomeric) flashings, such as polyvinyl chloride (PVC), Ethylene Propylene Diene Monomer (EPDM), and Thermoplastic Polyolefin (TPO) are synthetically manufactured. They have trouble when installed in lower temperatures, especially PVC. However, they are easy to fix when torn, or otherwise damaged, and can stick to themselves to allow easy overlaps for installation if bought in the peel n’ stick form.

Load bearing lintel detail with end dam shown over the flashing for clarity.
Figure 1:
Load bearing lintel detail with end dam shown over the flashing for clarity.

End dams are one of the most important parts of the flashing system. They prevent lateral movement of moisture, and protect the sides of an opening from water penetration. Joe Pullara, technical reviewer of FGM Architects, prefers to “place end dams at the edge of the lintel, past the openings.”

This is good practice, but hard to show in a two-dimensional drawing. Typically, a wall cross-section would be used to display the design on the lintel, including the moisture control with flashing. This view makes it difficult to identify end dams, and if they are not shown on the drawing, they may not be installed in the wall construction.

Take a look at Figure 1 of a window lintel with the end dam shown over the flashing for clarity, although in reality the end dam is placed first. Pat Conway, AIA, of the International Masonry Institute (IMI) said: “Components of the flashing system should be installed shingle-style. Since some end dams do not have adhesive backing, it is important to install [them] under the thru-wall flashing to better prevent moisture from moving laterally under the end dam.” To prevent installation error, it is good practice to detail end dam installation first.

Dale Kent’s experience comes from masonry restoration, and he now works with Facilities Engineering, Inc. “The wall I prefer to deal with is triple wythes of brick with arches on the openings,” he said. “The arch’s slope acts to direct the moisture away from the opening. Flat steel angles or I-beams allow places for moisture to pool above the opening, causing problems for the lintel. We typically will go in to repair that area, and often weld a plate at the crux of the steel shape. Then we will weld a new plate at an angle to pitch the moisture toward the weep vents.”

Because of cost constraints, it is uncommon to see three wythes of masonry in new construction, and likewise pitching the steel toward the exterior of the building requires specialty shapes that increase the cost. Knowledge of moisture movement is essential to funneling moisture out of an exterior wall.

Water requires a 2-percent grade, or one inch in elevation for every four feet of distance to move off a surface. Arches provide a natural method for moving moisture away from the opening. Curved arches require less maintenance over time compared with steel lintels with flat bases.

The main escape point for moisture from the wall is through weep vents. The Masonry Advisory Council (MAC), as well as the IMI, and Brick Industry Association (BIA) recommend using weep vents. Tubes and ropes are not recommended for adequately transmitting moisture out of a wall. Cell vents typically are placed at the head joint of exterior brick and have small holes to allow moisture to escape while preventing bugs, and other debris from entering the head joint.

Weep vents are great for removing water that is in their immediate vicinity, which MAC recommends being placed at 24 inches on center (tighter than the code required minimum). However, as discussed earlier, moisture will not move without having a pitch of 2-percent grade. This means that moisture in between weep vents will have trouble escaping if the moisture level is low.

Immediately following rain events, there would be enough moisture to provide the hydraulic head to push the water out of the weep vents through gravity, but as the height of water in the wall lowers, the amount of hydraulic head (hydrostatic force) diminishes. Without pitching of the steel toward the weeps, or toward the exterior of the building, small amounts of water still will remain in the wall pooled on the flashing.

During the construction process, mortar tends to fall into wall cavities when masonry units are laid, and the probability of mortar in the cavities increases greatly above two stories of height.

Colin Munro, the first executive director of the Illinois Masonry Institute (now known as the Masonry Advisory Council) said: “It is good to run the flashing up the wall higher than the mortar net.”

Running the flashing up the inside face of the cavity wall prevents any pooling moisture on the mortar droppings to enter the back-up wall, and eventually the building interior. Refer to Figure 2 for more clarity on the interaction between flashing level and the height of the mortar net in the cavity.

Mortar also can cause problems with moisture control where mortar fins protrude into the cavity, and can create a terminus in the cavity allowing moisture to pool. A necessary element of a wall that manages moisture is the air space, which allows the moisture to move in the wall to the drainage area above the openings. The minimum required air space in the Masonry Standard Joint Committee (MSJC) Code is one inch; however two inches is a good recommendation to provide air flow, and moisture drainage.

According to Kent, “Stainless steel creates a bond break at the sill, and with the fleece side up provides a continuous drainage plane. There also is no galvanic action between stainless steel and copper drip edges.” Receding the copper flashing into the wall will prevent the copper oxidation from staining the brick visibly when used with a stainless steel drip edge.

Properly detailed lintel with concrete masonry back up, and brick veneer.
Figure 2:
Properly detailed lintel with concrete masonry back up, and brick veneer.

A good detailing and installation technique is to apply the drip edge with caulking first, and then to apply the flashing over the drip edge receded one inch from the face of the facade.

Architects generally send their preliminary plans to engineers with the lintel material, shape, and location drawn in for the structural engineer to design. According to Barry Pecho, P.E., S.E., the senior structural engineer at Smith LaSalle engineering firm, collaboration is important.

“A designer will try and design the lintel to fit the shape that the architect has defined, and the most productive design for masons in the field,” Pecho said. “It is not uncommon to size beams based on the coursing of the masonry, or to try and replace a course of masonry in the wall with the lintel.”

The structural engineer and the architect, while collaborating to refine the design, should discuss the deflection of the lintel in regards to moisture control.

Longer spans, and spans with heavier load cause more deflection of the lintel. For example, L-angles typically deflect more than I-beams. Over the lifespan of the lintel, the steel will deflect. This deflection adds pitch to the beam toward the center that can be used to channel water.

“It is advisable to add two weeps closer together in the middle of a steel lintel where the water pools,” Pecho said. Arches also move the moisture to the edges. The water will run down the arch until the point where the thrust will be applied to the wall, the crux at the base of the arch. Target this area with an end dam and place a weep there to channel out the built up moisture.

Engineers seeking to design more masonry-arched openings should look toward BIA Tek note 31A, and “The Masonry Arch” by Jacques Heyman. Lastly, the IMI has a technical brief on the flashing of arches, “Tech Brief 2.7.5 Flashing Installation: Special Conditions steeped Foundations, Arches, and Pitched Roofs.”


Joe Packhem is a staff engineer for The Masonry Advisory Council. He is available to answer technical questions, and provide resources to those in the masonry industry. For advice, please contact Joe by email jpackhem@maconline.org, by phone at 1-847-297-6704, or by mail at 1440 Renaissance Dr., Suite 340, Park Ridge, IL 60068.
